is a dynamic zone mimic compatible with a range of fire alarm control panels, both addressable and conventional.

Utilising a 21.5” HD display, during a fire alarm event dynamicZM automatically displays an active fire alarm zone plan, clearly identifying the zone or zones in an alarm condition without user intervention.

For linked or non-fire zones, separate images or messages can be set for a clear and effective management of the premises.

During all other times when no fire alarm event is occurring dynamicZM is configured by the user to display their chosen media, including both images and silent video.

Each dynamicZM comes with free access to an online media manager dashboard to configure media and schedules, ready for local deployment to dynamicZM with a mobile device via Wi-Fi.

Should a fault occur with the remote PSU or the data connection between dynamicZM and the host fire alarm control panel, a general fault output is activated allowing full monitoring of the dynamicZM.

Additionally, a test facility is provided by way of a remote test switch. Activation of the test displays the configured fire alarm zone plan for 90 seconds to allow both the system coverage and building layout to be reviewed for accuracy on demand, without activating the fire alarm system.

dynamicZM is compatible with a range of conventional and addressable fire alarm panels from:

Download data sheets
